Building a Distributed Job System with Java RMI: Peer Discovery, Leader Election, and Thread Safety

Written by Rohan Nandan on September 28, 2026 · 9 min read

Source: github.com/SRVSRR/distributed-job-processing-system

For CS324 Assignment 1, our group of four built a Java 17 + Maven + Java RMI cluster that runs data-parallel jobs across an unstructured peer-to-peer worker overlay under an elected coordinator. Looking back, the project had a natural question order: workers had to find each other first, which forced us to justify the bootstrap, which raised the centralisation question, which left jobs needing a scheduler, which needed an election, which needed message suppression, which needed thread safety. This post follows that order, with the reasoning we used at each step.

The Pieces

Joining the Network

The first problem we hit was the oldest one in peer-to-peer systems: a new worker knows nothing except one address. We gave it the bootstrap node, and joining worked like this:

1. BootstrapNode.main creates or locates the RMI Registry and rebinds "BootstrapNode".
2. Each WorkerNode(id, host, port) binds as Worker-<id>, looks up the bootstrap node, and calls registerWorker(id, rmiAddress), which rejects duplicate IDs, picks a random existing worker address via ThreadLocalRandom as the join peer, and stores the mapping in a ConcurrentHashMap<Integer, String> of active workers.
3. The new worker looks up that peer and creates a bilateral neighbour link (addNeighbor both ways). The result is a random unstructured graph held in a CopyOnWriteArrayList<WorkerInterface> of neighbours.
4. Workers stay alive via Thread.currentThread().join(). We made election lazy — it only happens on the first submitJob — so a cluster can form with no coordination traffic at all. A shutdown hook deregisters the worker.

We kept coming back to why a bootstrap was needed at all, and the answer settled into three roles. It is the rendezvous for unstructured join: the joiner attaches to the graph without any global configuration. It is the unique-identity and membership directory: synchronized registration enforces unique integer IDs, deregisters on shutdown, and serves snapshots. And it is the discovery service for clients and coordinators: both ClientService.activeWorkerAddresses and WorkerNode.discoverActiveWorkers depend on bootstrap.getActiveWorkers() to resolve stubs and to size partitioning — the worker count determines the partition count, and the client prefers a live coordinator without tracking leadership itself.

We also considered what would replace it. Any peer-discovery mechanism works: a static peer list or config file tried sequentially, UDP multicast or mDNS announcements on the LAN, gossip from hardcoded seed nodes with epidemic neighbour-list exchange, a structured overlay like Chord or Kademlia for deterministic lookup, or an external registry such as DNS-SRV, etcd, or RMI registry scanning. The trade-off is the same everywhere: every alternative removes the single well-known address but adds complexity, network assumptions, or still needs at least one known seed. For an assignment cluster, the bootstrap was the right call.

Centralised?

A bootstrap that everything registers with sounds centralised, and our marker would absolutely ask, so we settled this early: the system is decentralised with a centralised directory bootstrap — a hybrid, not centralised control.

The bootstrap is never on the data or control hot path. After registration, job submission, partitioning, executeWorkUnit, election flooding, and COORDINATOR floods are all worker-to-worker RMI over neighbour stubs. The bootstrap never computes, aggregates, elects, or forwards jobs. It holds no coordinator role either: leadership, JAC accounting, and term rotation are fully peer-executed, and any worker can initiate an election or become coordinator. And failures are isolated — if the bootstrap crashes after formation, in-flight jobs and elections among already-connected neighbours continue. Only new joins, client bootstrap queries, and coordinator discoverActiveWorkers snapshots degrade: a membership-availability loss, not a compute or coordination single point.

The honest caveat, which we flagged in our report, is that it is a logically centralised membership SPOF sharing a host with the RMI registry. Given more time we would have replicated the directory, cached membership and gossiped neighbour lists, or let the coordinator fall back to neighbour-graph traversal when the bootstrap is unreachable.

Running a Job

With workers connected and the directory question settled, we wired up the end-to-end job path. The supported ComputeOperation values are MAX(list), PRIMECOUNT(list), and PRIMESUM(start, end).

1. The client sets host, port, and client ID. A poll timer shows the live worker count via bootstrap.getActiveWorkers().
2. The user enters 2,4,5,11 or loads a CSV (data/numbers-sm/md/lg.csv). JobParser handles list versus start,end input, headers, and ;, ,, and whitespace separators.
3. JobRequest validates immutably: MAX needs a non-empty list, PRIMECOUNT allows empty (returns 0), PRIMESUM requires start<=end.
4. ClientService.submit fetches addresses, resolves stubs, sorts coordinators first, and tries each in order with failover to the next worker on RemoteException.
5. Any WorkerNode.submitJob that is not the coordinator calls forwardJobToCoordinator — and if its coordinatorRef is not live, it runs initiateElection() first, then forwards.
6. The coordinator’s executeDistributedJob admits the top-level job (incrementing the JAC and term counters), discovers active workers through bootstrap.getActiveWorkers() plus Naming.lookup sorted by ID in a TreeMap, partitions with WorkPartitioner.partition(request, N) into balanced contiguous splits (min(N, size), remainder distributed one-extra to the first partitions; range jobs split by arithmetic sub-ranges), fans out one WorkUnit per worker via a dispatch executor with blocking future.get(), then aggregates with ResultAggregator.aggregate (validating job, operation, and partition IDs, rejecting duplicates and missing pieces; MAX takes the max, PRIMESUM/PRIMECOUNT sum exactly). After the fifth job of a term finishes, a re-election is triggered.

ComputeEngine itself we kept deliberately boring: linear max, trial-division isPrime (divisor <= n / divisor), plus primeSum and primeCount built on top. The interesting work was never the arithmetic — it was getting the units to the right machines and the answers back.

Step 5 left the next problem staring at us: somebody has to be the coordinator, and there is no central authority to appoint one.

Electing a Coordinator

We went with flooding + convergecast (echo) over the neighbour graph, triggered on demand and on term expiry. Election IDs look like ELECTION-<initiator>-<seq>; coordinator announcements look like COORDINATOR-<electionId>. propagateElection(id, sender) floods depth-first to all neighbours except the sender, each subtree returning its best Candidate up the recursion. Candidate.isBetterThan implements the rule we agreed on: lowest JAC wins, ties broken by highest worker ID — least-loaded first, deterministic fallback. The initiator collects the child bests, picks the winner, carries the winner’s RMI stub inside the Candidate to avoid a lookup, installs the state locally, then floods the decision with propagateCoordinator.

We added term rotation because a coordinator elected once would otherwise serve forever, accumulating state and becoming a de-facto single point. Terms are capped at MAX_JOBS_PER_TERM = 5. The jac counter is an AtomicInteger incremented per coordinator admission, and jobsInCurrentTerm, termClosing, termTransitionStarted, inFlightJobs, and coordinatorTermSequence together enforce a single coordinator per term. The fifth admission sets termClosing = true; once in-flight jobs drain to zero the node steps down and triggers initiateElection exactly once. A live-coordinator guard in initiateElection aborts if coordinatorRef.isCoordinator() is still true.

Flooding an unstructured overlay forced the subtlest correctness question of the project: random bilateral links inevitably create cycles and multiple paths, so a naive flood would circulate forever, arrive many times at each node, storm the network, recurse until stack overflow, double-count subtrees, and flap the coordinator ID. Our fix was duplicate suppression with two seen-sets:

seenElectionIds = ConcurrentHashMap.newKeySet();
seenCoordinatorIds = ConcurrentHashMap.newKeySet();

propagateElection(id, sender) {
  if (!seenElectionIds.add(id)) return null; // duplicate
  ... flood to neighbours except sender ...
}

propagateCoordinator(msgId, ...) {
  if (!seenCoordinatorIds.add(msgId)) return; // duplicate
  ... install state, flood except sender ...
}

The initiator pre-adds its own election and coordinator IDs before flooding, so its own echo is ignored. Candidate.betterOf(best, null) = best makes duplicate null returns harmless to the convergecast. An electionLock serialises concurrent local initiations, and sender-exclusion prevents immediate ping-pong. In retrospect this was the highest-value dozen lines in the codebase: suppression turns the flood into a spanning-tree traversal where each node expands once per election ID, which guarantees termination, exactly-once contribution to the convergecast, and eventual agreement on a single coordinator.

Threads and Shared State

Everything above runs concurrently — remote fan-out, RMI callbacks landing on worker threads, elections firing mid-job — so the last thing we had to get right was the shared state underneath it all.

Threads in use:

• Worker: a fixed pool of 4 in computeExecutor running computeWorkUnit via submit(...).get() inside executeWorkUnit; a fixed pool of 4 in dispatchExecutor for parallel remote fan-out in executeDistributedJob; RMI runtime threads serving concurrent submitJob / propagateElection / propagateCoordinator / executeWorkUnit callbacks; a shutdown-hook thread for deregistration and executor shutdown; the main thread parked on join.
• Bootstrap: RMI dispatch threads serving concurrent register, deregister, and get calls.
• Client: a fixed pool of 8 for submits plus worker-count polling, one SwingWorker per job to keep the EDT responsive, a 2-second poll timer, and the EDT itself for table updates via invokeLater.

The safety mechanisms we relied on, with examples:

• Lock-free concurrent collections. ConcurrentHashMap for active workers, newKeySet() for the seen election/coordinator IDs, CopyOnWriteArrayList for neighbours — safe to iterate during a flood while addNeighbor mutates. getActiveWorkers returns a defensive copy.
• Atomics and volatiles. AtomicInteger for JAC and jobs-in-term, AtomicLong for the election sequence, client-side AtomicInteger job counters; volatile for the coordinator flag, ID, and reference so leadership is visible without locking.
• Explicit locks. synchronized register/deregister for check-then-act unique-ID enforcement; one electionLock so a node runs a single election at a time with the alive-coordinator check done atomically; a termStateLock guarding the term flags and counters across admission, completion, and coordinator installation. We kept lock ordering consistent (electionLock before termStateLock, never reversed), and blocking future.get() or remote calls are never held inside the term lock except for short state mutation, which avoids deadlock.
• Immutability. JobRequest, WorkUnit, and WorkResult are records with List.copyOf; the partitioner and worker-list helpers return copies — all freely shared across threads and RMI boundaries. This decision saved us from an entire class of aliasing bugs.
• Executor hygiene. Bounded named pools, RejectedExecutionException converted to RemoteException, dispatch cancellation with future.cancel(true) plus interrupt-status restore, and orderly shutdown() / awaitTermination(5s) / shutdownNow() sequencing.

Conclusion

Looking back, the architecture reads as a chain of answers: the bootstrap made the system joinable without touching a job; flooding with duplicate suppression made elections correct on a cyclic overlay; term rotation kept any coordinator from becoming permanent; and lock-free structures, atomics, a strict lock order, and immutable messages kept the concurrency tractable. The single deliberate compromise was the centralised membership directory — cheap to build, easy to reason about, and the first thing we would replicate with more time. For a four-person team splitting peer logic, coordination, and client work, the clean module boundaries were what let us integrate without stepping on each other.
